TP-Link TL-SG3428 | Switch | 24x RJ45 1000Mb/s, 4x SFP, Managed, L2

TP-Link TL-SG3428 L2 JetStream Managed Switch

The TP-Link TL-SG3428 managed switch features 24 RJ-45 GE ports, four SFP slots for optional network branching, RJ-45 console ports and microUSB for PC control. The throughput of the switching matrix is 56 Gbps. The packet forwarding rate is 41.66 mpps. MAC address table capacity – 8K. packet memory buffer – 4.1 MB. For new generation networks based on IPv4 and IPv6 protocols, dual stack IPv4 / IPv6 support is available (16 IP interfaces). Supports IGMP Snooping – network traffic tracking with filtering to optimize the transmission of multicast streams.

A huge number of essential and high-quality functions

Enterprise level QoS technology (IEEE 802.1 p COS / DSCP, 8 priority queues), voice VLAN, ACL access control lists provide prioritization of voice and video applications, intelligent distribution of network traffic. A feature set is available for ISPs: QinQ, PPPoE ID Insertion, L2PT, etc. the 802.3 ah OAM and DLDP protocols make it easy to monitor and correct Ethernet failures.
The switch supports traditional management functions: command line interface (CLI) via console port and telnet protected with SSH v1/SSH v2 traffic encryption and graphical web interface (GUI) protected with HTTPS encryption with SSL V3 (vulnerable protocol, required for Systems with Internet Explorer 6 and Windows XP without SP 3) and TLS1.2.

High security in one device

TL-SG3428 includes tools to ensure high network security through IP/IPv6-MAC port binding, port and LAN protection, protection against DoS attacks and broadcast storms, DHCP Snooping function, etc. ACLs (L2-L4) restrict access to significant network resources with packet rejection based on IP address, MAC address, VLAD ID, TCP/UDP ports. The 802.1x standard enables authentication through RADIUS/Tacacs servers . Logging for clients without 802.1 x-through the guest VLAN.

Main features and benefits

• Gigabit Ports: 24 Gigabit RJ45 ports and 4 Gigabit SFP slots provide high connection speeds.
• Omada SDN: The platform provides access to unattended ZTP configuration, central cloud management, and intelligent monitoring.
• Centralized Management: Management is extremely convenient via cloud access and the easy-to-use Omada application.
• Static Routing: Allows you to direct network traffic for efficient use of network resources
• Strong Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication and more.
• Voice and Video application optimization: L2/L3/L4 QoS and IGMP snooping.
• Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON and Dual Image provide extensive management capabilities
