Orvaldi sinus 600 LCD | UPS | 600VA/360W, 7Ah

Orvaldi sinus 600 LCD – intelligent microprocessor control

This model is a small UPS with pure sine wave output for computer protection with a demanding switching power supply and active PFC filter; ideal for powering CO stove pumps or fireplace pumps.

TheOrvaldi Sinus 600 LCD is an advanced UPS in line-interactive topology based on full microprocessor control. Sinus 600 LCD works with the latest technology and high efficiency to deliver pure sine wave to the protected loads both in mains and battery operation. This model stands out:

• The shape of the voltage at the UPS output,
• very quiet operation during battery mode

Thanks to these features, the versatility of application of this device serves a wide range of switching power supplies (passive PFC) . If we encounter a situation in which there is a break in the supply voltage, it can immediately supply the energy stored in the batteries without any interruption. The switching time to battery operation and vice versa is carried out within 2 to 10 ms .

What are the characteristics of the Orvaldi Sinus 600 LCD?

• Provides pure sinusoidal output voltage shape,
• Excellent power protection for servers, gaming PCs and any load with active PFC filter,
• Boost and AVR for voltage stabilization,
• Three-stage charging optimizes battery performance,
• With built-in USB and RJ-45 communication port

Battery voltage in UPS	12V
UPS power (VA)	600
Audible alarm modes	Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Audible alarm(s)	Yes
Battery capacity	7
Battery voltage	12
Depth	328
Form factor	Compact
Height	145
Input frequency	50/60
Input operation voltage (max)	240
Input operation voltage (min)	220
Number of batteries supported	1
Output power	360
Output power capacity	0.6
Product colour	Black
UPS topology	Line-Interactive
Waveform	Pure sine
Weight	5.2
Width	100
