Orvaldi i600LCD USB | UPS | 600VA/360W, 7Ah

ORVALDI i600 LED

It is an advanced UPS unit in line-interactive topology based on full microprocessor control. Additionally equipped with a USB charger. Used with the latest technology and high efficiency to provide power to the protected loads both when working with the network and when working from the battery. The voltage shape is economical at the output of the UPS and is characterized by a very quiet operation during battery mode, which ensures the universality of application of this device to a wide range of switching power supplies (passive PFC) . In case of interruption of the supply voltage, it can immediately supply the energy stored in the batteries without any interruption. Switchover time to battery operation and vice versa is typically carried out within 2 to 6 ms.

What are the characteristics of ORVALDI I600 LCD USB?

• „Green topology” saves 50% more energy than other UPSs in its class.
• Built-in intelligent charger provides 90% charge in just 5 hours.
• Superior microprocessor control ensures high reliability.
• Dual Boost and Buck AVR for voltage stabilization.
• Auto-restart when AC supply voltage returns.
• Simulated sine wave (approximate).
• Cold start function.
• Easy to read LCD display indicating UPS operating status.
• 5V charger on 2 USB ports

on the front panel (max. 2.4 A).

• ---



Battery voltage in UPS	12V
UPS power (VA)	600
Battery capacity	7
Battery voltage	12
Depth	316
Form factor	Compact
Height	141
Input frequency	50/60
Input operation voltage (max)	240
Input operation voltage (min)	220
Output power	360
Output power capacity	0.6
Product colour	Black
UPS topology	Line-Interactive
USB port	Yes
Waveform	Pseudo sine
Width	100
