Mantar SM-50/55/41 Rack 19″ 9U | Outdoor cabinet | IP65, depth 410 mm

Mantar outdoor cabinet SM-50/55/41 RACK 19″ 9U hermetic

Mantar external cabinet SM-50/55/41 RACK 19″ 9U hermetic is designed to be mounted using pole brackets, optionally wall mounted in offices, network server rooms and CCTV control rooms. The external walls are made of steel sheet. The cabinet is resistant to corrosion (covered by a 5-year warranty), hermetically sealed, sheet metal with Magnelis® coating 1.0mm thick, light gray color. It constitutes a mechanical shield for telecommunication equipment. Cabinet does not include in the set of cybants (holes prepared for 50mm and 100mm spacing).

Features:

Features:

• Hermetic, made of sheet metal with Magnelis® coating 1 mm thick
• Degree of protection IP65, mechanical resistance IK10
• Powder-coated, colour: RAL7035- light grey, thick structure
• Locked with a hermetic lock
• The cabinet has additional body reinforcements in place of mounting holes
• Standard equipped with 6 holes ø24 mm, located in the bottom wall, covered with hermetic chokes
• 19″ 9U vertical rack handles – standard (distance between handle face and door is 80mm)

Additional equipment:

Additional equipment:

• Shelf 19″ 1U deep 200mm (rack-mounted)
• Set of post holders
• PS 19″ 1U 24 x SC Duplex/Simplex pull-out
