Extralink VICTOR | PoE Switch | 8x Gigabit PoE/PoE+, 2x SFP, 1x Console Port, 150W, Managed

Extralink Victor – multi-purpose PoE switch

VICTOR is a managed PoE switch, ideal for powering WIFI AP, IP cameras, WIFI bridges, IP phones and other types of network devices. The product has 8 Gigabit PoE ports and 2 uplink SFP ports, complete security mechanisms, improved ACL/QoS functions and rich VLAN capabilities. It is easy to manage and meets user requirements for high level of security.

Main features of the VICTOR switch:

Main features of the VICTOR switch:

• Ports -1-8 supports PoE power supply up to 250 meters (recommended cat 5e, 6 or higher mains cable)
• Support for isolation of ports from each other with a VLAN switch, which can effectively stop broadcast storms, improve network performance. VLANs can also be configured as needed via WebUI
• Supports IEEE 802.3af/at, automatically detects and identifies and powers IEEE 802.3af/at compliant devices
• Auto MDI/MDIX support
• Power circuit protection, protects devices connected to the switch
• Support for energy saving in unused ports
• All ports have the ability to set the link speed
• Easy to use

Description of the functional switches:

– QOS: Improving video data processing, ideal for monitoring applications

– EXTEND: Capacity on ports 1-8 drops to 10Mbps, but PoE transmission range increases to 250 meters

– VLAN: Isolating ports 1-8 from each other, effectively attenuating network storms and improving network performance

– AI PS: Detection of failure/suspension of a device connected to the PoE port and restarting the power supply on that port
